The CI-V is accessed via USB or the CI-V jack plug (called REMOTE by Icom) By default, these are connected internally, see this image below.
going from digital to analog to digital domain again, solves all sample rate conversion issues. From a practical point of view, this is the best solution, although theoretically it might be questionable. Actually, when you analyze the schematics, you’ll see that the build-in interface does not differ from most external interfaces: the decoded analog audio is actually converted to digital again in the USB Audio CODEC. There is nothing Icom specific in the USB part of the IC-7300.
#Best usb serial adapter icom remoe driver#
The Audio CODEC inside the IC-7300 does not requires a separate driver install.
#Best usb serial adapter icom remoe install#
No need to install the Icom supplied driver. This driver is automatically installed when on Win8.1 or Win10. I do not make any representation or guarantee that this circuit will function, nor do I accept any responsibility whatsoeverįor any damage or malfunction arising from the use of this circuit.The SiLabs CP210x USB to UART (Serial Port) bridge chip inside the IC-7300 needs a driver. So just get a USB interface from eBay.ĭisclaimer: Although I have tested and used the above circuit on my own IC735 and IC706mkIIG with no problems,
#Best usb serial adapter icom remoe drivers#
The workaround is to use the drivers supplied for Vista.Īlthough I have successfully used the interface with a serial-USB adapter, I have seen USB CI-V cables from China at very cheap prices on eBay.Ĭonsequently, if your PC/Laptop has no serial ports, it's hardly worth the effort of building this interface nowadays. The drivers supplied with Windows7 & Windows8 will result in an "Error 10" when they detect the counterfeit chip. When Prolific discovered this, they amended their drivers to detect counterfeits. Many of these use counterfeit Prolific PL2303 chips. If you intend using this interface with a USB/Serial adapter, beware of a possible issue with many of the cheap adapters available on eBay.
Probably the interface can be used with other HTs, although I have not tried it. Only a change of connector to a 4 pole minijack plug was required. I have also used this interface to program my Yaesu FT50R. To test and/or debug the interface, I would strongly recommend using AA6YQ's CI-V Commander program. This is easily resolved by powering the circuit from RTS (pin 7) instead of DTR (pin4). The program drops the DTR signal, resulting in no power to the interface. If YPLog is configured to use PTT from either the Parallel port or a different serial port from the one used by the CI-V Interface, I experienced some problems with YPLog using this power source. If a PTT function is required from the COM port, pin 7 (RTS)
Using a USB/Serial adapter from a notebook. No problems have been experienced even at 19200 baud with the IC706. It has also worked successfully when I've used this interface on various PC's and also Dell Latitude Notebooks with both an IC735 and IC706MkIIG. The transistor types are not critical, I just happen to have plenty of 2N2222As. Please note that the resistor value 4K7 means 4700 ohms. It does work well and has the advantage of being easily constructed inside a 9 pin D-type shell. Although the circuit doesn't conform exactly to the RS-232 specification, I've made small changes to the modemĬontrol signals connections. Here is a very simple CI-V interface, originally described by A few circuits have been published for CI-V interfaces, most of which Icom appears to delight in charging outrageous prices for all transceiver accessories,
